Applications:

    Ground fault protection

    Transformer protection

    General application - for any electrical load monitoring

    Motors - monitoring conditions such as overload, locked rotor, etc.

    Genset - to ensure load current is within generator capacity

    Over current protection

    Under current protection

    Current unbalance protection

Product Features:

Protection feature:

    Over Current Protection

    Under Current Protection

    Current Unbalance Protection

Nominal current setting:

    Nominal current can be set from 1A- 5A

Adjustable trip point:

    Trip point adjustment for Under current and Over current

    Unbalance current tripping:

    Unbalance current tripping feature can be enabled /disabled on site by using front key . This fault is disabled on factory setting

Adjustable hysteresis:

    Hysteresis adjustment for Under current and Over current

Adjustable Time delay for:

    Under Current

    Over Current

    System types:

    Available in Single phase and Three phase option

Relay option:

    Relay option 1CO, 1CO+1CO is available

Auto/Manual reset:

    In auto mode relay automatically clears itself if it comes out of the fault condition. If relay set in manual mode, the device must be manually cleared by “PRG/RST” key when fault condition is recovered.

    Auto / manual resetting feature can be enabled /disabled on site by using front key

Compliance to International Safety standards:

    Compliance to International Safety standard IEC 61010-1- 2010

True RMS measurement:

    The instrument measures distorted waveform up to 15th harmonics

    LED Indication:

    LED indication for Power on, Under current,

    Over current, Current unbalance

Relay operation:

    Relay energize and de-energize on fault option available
